Description
Dartmoor, and NS Bikes have a long history in the business of building dirt jump bikes, and components. The hubs in question make a wheelset that will perform day in and day out.
Hub Specs
- Dartmoor Reel Non-disc front hub, NS Bikes Rotary Single rear hub.
- 100x15mm or 110x20mm spacing in the front (endcaps for both fitments are included with the delivery), 135x10mm bolt-on in the rear.
- 32H spoke hole counts. 6-bolt rotor interface in the rear, none in the front.
- Single-speed freehub driver body with a 10T cog.
- Reliable pawl-style freehub mechanism.
Rims
The wheels are built around NS bikes Fundamental 26″ rims.
Spokes & Nipples
Wheels are built with double-butted Sapim Race spokes that employ a 2.0/1.8/2.0mm profile. The Race spokes are the default spoke choice for multiple reasons.
- Excellent strength-to-weight ratio.
- Better fatigue-resistance properties than straight gauge 2.0mm spokes.
- Excellent value, and availability.
Race spokes are mated with with black-coloured Sapim Polyax Double Square nipples. Brass nipples are used exclusively in builds because of their reliability, low to zero maintenance needs, corrosion resistance and strength. Reliability, and function are further enhanced by using the Secure-Lock version of the said nipples, or by adding a mild adhesive compound with traditional nipples.
Build
Unless otherwise specified by the component manufacturer, all wheels are built with the following properties:
- Lacing pattern according to the hub specification.
- Thorough stress-relieving process.
- Highest tension approved by the component manufacturer – usually 1200N.
- With a high degree of trueness, and roundness.
The whole build process is made by hand.
Lead Time
All wheels are built to order. Shipping takes place usually within 3-6 working days after the order has been placed.
Once finished, and shipped, the relevant tracking code will be forwarded by email.
