Description
Onyx Racing Products hubs are synonymous with BMX racing in the highest levels. The patented sprag clutch mechanism offers legendary performance that is coupled with 2nd-to-none function, and reliability, granted by the robust hub shells, and the largest bearings found on any hub!
All Onyx Racing Products hubs are made in the USA.
Hub Specs
- Onyx Racing Products BMX front hub with 100x20mm thru-bolt axle.
- If a 100x10mm bolt-on axle is desired instead, please get in touch by email.
- Onyx Ultra BMX ISO rear hub is available in two axle spacing standards: 110x10mm bolt-on or 110x15mm thru-bolt.
- The front hub is supplied with a 20x114mm front axle.
- 36H spoke hole counts. 6-bolt rotor interface in the rear.
- Traditional HG freehub driver body standard.
- Patented sprag clutch mechanism which offers instant engagement, silent operation, and nearly zero-drag performance!
Rims
Wheels are offered with a variety of Pro 20″/406mm rim options to suit the intended application, including differing internal widths, and rim materials. See the continually updated rim choice page by clicking the link below to find the right match for your needs.
Spokes & Nipples
Wheels are built with double-butted spokes that employ a 2.0/1.8/2.0mm profile. The Race spokes are the default spoke choice for multiple reasons.
- Excellent strength-to-weight ratio.
- Better fatigue-resistance properties than straight gauge 2.0mm spokes.
- Excellent value, and availability.
Brass nipples are used exclusively in builds because of their reliability, low to zero maintenance needs, corrosion resistance and strength. Reliability, and function are further enhanced by using the Secure-Lock version of the said nipples, or by adding a mild adhesive compound with traditional nipples.
Build
Unless otherwise specified by the component manufacturer, all wheels are built with the following properties:
- Lacing pattern according to the hub specification.
- Thorough stress-relieving process.
- Highest tension approved by the component manufacturer – usually 1200N.
- With a high degree of trueness, and roundness.
The whole build process is made by hand.
Lead Time
All wheels are built to order. Shipping takes place usually within 3-6 working days after the order has been placed.
Once finished, and shipped, the relevant tracking code will be forwarded by email.
